Product Description
Robot arm 5-Axis zero backlash 1:80 ratio gear reducer harmonic drive gearbox CSG series
- ✓ Compact design
- ✓ High torque capacity
- ✓ Zero backlash
- ✓ Excellent positioning accuracy
- ✓ Coaxial Input and output
CSG harmonic reducer is used for high torque cases, its torque is 30% higher than CSF reducer’s, and the life time is 43% longer (10,000 hours). CSG/CSF-2UH series harmonic drive units are available in ten sizes with gear ratios of 50, 80, 100, 120 and 160:1 offering repeatable peak torques from 23 to 3419 Nm.
The output bearing with high tilting rigidity enables the direct introduction of high payloads without further support and thus permits simple and space saving designs. Standard servo motors can be attached in a compact manner. The harmonic drive gearboxes cover a wide torque range and feature long service life, confirmed by many years of successful service. Unit and motor together form a compact and lightweight system capable of quickly withstanding high loads. Due to the Units positioning accuracy, stable machine characteristics with short cycle times are guaranteed.
CSG & CSF series combination harmonic gearbox can meet the request of high function, high speed, high load capacity, high density, subtle and accelerate the demand of the technical innovation. Difference between CSG series and CSF series is that CSF series harmonic gearbox is with standard torque, while CSG series harmonic gearbox is with higher torque and longer service time.
| Type |
CSG harmonic drive gearbox |
| Color |
Silver |
| Packing |
Carton, Honey Comb Carton, Wooden Case with wooden pallet |
| Warranty |
1 Year |
| Input Power |
0.05kw, 0.1kw, 0.2kw, 0.4kw, 0.75kw, 2kw, 2.5kw, 5kw, 11kw, 15kw |
| Usages |
Industrial Machine: Food Stuff, Ceramics, Chemical, Packing, Dyeing, Wood working, Glass, New energy, Mine, Heavy industry equipment, Industrial automation |
| Lubricant |
Special gear oil |
